Rated power kW

41

55

77

86

Rated voltage

537V

Input voltage AC

3~ 400VAC

Input frequency AC

50/60 Hz

Input connector AC

CEE 3~, 63A

Input connector DC charging

CCS2

Output connector AC

CEE 3~ 63A, 32A, 16A; CEE 1~ 16A

Output connector DC charging

CCS2, 1pc

Output power DC charging kW

40

40

60

80

Output voltage DC

150~1000VDC

Cooling method

air cooling

Noise

≤ 65dB

Communication protocol

OCPP 1.6J

HMI

7-inch touch screen

Charging mode

full charge, target energy, target money, target time

Payment method

RFID card, QR code, APP

Installation

Ground installed or mobile

Charging standards

IEC 61851-23, ISO 15118-2

IP rating

IP54

Operating temperature

-35°C ~ +55°C

Relative humidity

5% ~ 95%

Network connectivity

4G, Ethernet

Safety and protection

Over and under voltage protection, overload protection, current leakage protection, over temperature protection, low temperature protection, grounding protection, lightning surge protection, anti-static protection, emergency stop, insulation control

Other features

Built in STS function for automatic switching of power supply from grid and battery, and automatic sensing of on grid and off grid;

Built in EMS for automatic self battery charging, and automatic battery discharging for AC output.

PV integration

Optional, 60~80kw

Weight

1000~1500kg
